Frameset
- SWAT: SWAT internal downtube storage
- Frame: M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- Seat Binder: Alloy, 38.6mm
Suspension
- Rear Shock: X-Fusion 02 Pro RL, Ride Dynamics Trail Tune, rebound adjust, lockout S1:210x52.5mm, S2-S6:210x55mm
- Fork: RockShox, Psylo Silver, Motion Control Damper, 15x110 axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
Brakes
- Rear Brake: Shimano, BR-MT420, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 203mm
- Front Brake: Shimano, BR-MT420, 4-piston caliper, hydraulic disc, 203mm
Drivetrain
- Chain: Shimano Deore, M6100, 12-speed
- Crankset: Shimano Deore, M6120, 30T ring, 55mm chainline, S1-S3:165mm, S4-S6: 170mm
- Cassette: Shimano Deore, M6100, 12spd w/Hyperglide+, 10-51t
- Rear Derailleur: Shimano Deore, M6100, 12pd, Shadow Plus
- Shift Levers: Shimano Deore, M6100, 12spd
Wheels & tires
- Rear Tire: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
- Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
- Rims: Specialized Alloy, Tubeless Ready, 29mm internal width, 28h, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
- Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
- Spokes: Stainless, 14g
- Inner Tubes: Standard, Presta valve
- Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Cockpit
- Stem: Alloy Trail Stem, 35mm bar bore
- Saddle: Bridge, Steel rails, S1-S2: 155mm, S3-S6: 143mm
- Handlebars: Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise
- Grips: Specialized Trail Grips
- SeatPost: TranzX Dropper, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 200mm
- Weight: 16.57 kg (36 lb, 8.5 oz)
- Weight Size: S4
